SMT Offline Testing Machine
SMT Offline Testing Machine
Description
State of the art optical system.
Easy to learn, easy to operate.
Fast detection speed.
Rapid improvement of the company's market competitiveness.
Reliable performance.
Specification
Product name: SMT Offline Testing Machine
PCB Thickness: 0.3-8.0mm (PCB bending:≤3mm)
PCB element height: Upper 50mm Lower 50mm
Drive equipment: Panasonic servo motor
Motion system: High precision screw + linear double guide rails
Positioning accuracy: ≤10μm
Moving speed: Max.700mm/sec
Power Supply: AC220V 50HZ 1800W
Environmental requirements: Temperature: 2~45℃, relative humidity 25%-85%(frost free)
Dimensions: L875*W940*H1350mm
Weight: 600KG
Optical System
Detection method: Template matching,luminance extraction, luminance average, brightness minimum, brightness maximum color extraction, circular detection Character detection, offset detection, angle detection, etc
Industrial camera: 1 set of high-definition color camera, HIKVISION or Basler optional
Iight source: 1 set of RGB circular multi-angle LED light source
Camera lens: 1 set of high-definition telecentric lenses, DOF: 4mm
Resolution: 15μm Standard（10μm, 15μm, 20μm Optional）
Our Service
1. More Professional service in PNP machine field.
2. Better manufacture ability.
3. Various payment term to choose: T/T, Western Union, L/C, Paypal.
4. High quality/Safe material/Competitive price.
5. Small order available.
6. Quickly response.
7. More safe and fast transport.
About Us
Our Factory
Zhejiang NeoDen Technology Co., Ltd. founded in 2010. In this decade, we independently developed NeoDen4, NeoDen IN6, NeoDen K1830, NeoDen FP2636 and other SMT products, which sold well all over the world.
We believe that great people and partners make NeoDen a great company and that our commitment to Innovation, Diversity and Sustainability ensures that SMT automation is accessible to every hobbyist on everywhere.
① R&D Center: 3 R&D departments with 25+ professional R&D engineers
② Listed with CE and got 50+ patents
Certification
Exhibition
If you need, please feel free to contact us for more information.
