- Clean the net stipulation uses the cloth to touch the alcohol to clean, cannot pour the alcohol directly to the steel net and so on.
- It is required to go to the new program to check the position of the scraper printing stroke each time. Both sides of the y-direction scraper stroke should exceed the opening of the most edge element by 10MM.
- Visually check whether the steel mesh cleaning machine can reach the steel mesh when the machine is performing automatic cleaning. If it cannot reach the steel mesh, inform the engineer to deal with it in time.
- Do not press END RUN when PCB loader machine on working.
- Take care to hold and steady the scraper in disassembly and installation, otherwise the scraper will fall on the steel net, which will cause damage to the steel net and the scraper.
- Be sure to add the support bar after lifting the head.
- During the operation of the machine or under the state of waiting to enter the machine, the manual plate cannot be picked into the machine, and the hand cannot be extended into the machine. The safety cover cannot be opened. The stirring knife should not be placed in the air of the machine.
- Two people cannot operate the machine at the same time.
- When rotating the monitor of a machine, it is necessary to make sure that there is no person or other object in the scope of the monitor.
When opening or closing the safety cover of the machine, it is necessary to open the safety cover of the machine after printing the plate inside the machine. - If the machine fails and needs to be shut down, the machine should be shut down and started again, with an interval of over 30 seconds.
- Press the emergency stop button to inform the engineer on duty to deal with any abnormal operation of the pick and place machine.
- Clean the solder paste and other sundries on the conveyor belt and inside the machine frequently.
